Ultrasonic Wind Speed Direction Air Temperature Humidity Pressure Solar Radiation Radar Rainfall 7 in 1 Weather Station

Q: What's the main characteristics of this compact weather station?
A: It can measure the air temperature humidity pressure wind speed wind direction rainfall illumination 7 parameters at the same time, and the other parameters also can be custom made.The principle of radar rainfall monitoring,Compared with the tipping bucket rain gauge, maintenance-free, high accuracy; Compared with the infrared rain gauge, more anti-interference, more accurate measurement.It is easy for installation and has robust & integrated structure, 7/24 continuous monitoring.

Q:Can we choose other desired sensors?
A: Yes, we can supply the ODM and OEM service, the other required sensors can be integrated in our present weather station.

Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.

Q:Do you supply tripod and solar panels?
A: Yes, we can supply the stand pole and the tripod and the other install accessories, also the solar panels, it is optional.

Q: What’s the common power supply and signal output?
A: Common power supply and signal output is DC: 12-24V, RS485. The other demand can be custom made.

Q: Which output of the sensor and how about the wireless module?
A: You can use your own data logger or wireless transmission module if you have , we supply the RS485-Mudbus communication protocol.We can also supply the matched LORA/LORANWAN/GPRS/4G wireless transmission module.

Q:What communication interface do you prefer?
Q:We have RS232, RS485, SDI-12 for your option.

Q:What communication protocol do you prefer?
Q:We have NMEA0183, MODBUS-RTU, SDI-12,unsolicited ASCII string output for your option.

Q: How can I collect the data and can you supply the matched server and software?
A: We can supply three ways to show the data:
(1) Integrate the data logger to store the data in the SD card in excel type
(2) Integrate the LCD or LED screen to show the real time data indoor or outdoor
(3) We can also supply the matched cloud server and software to see the real time data in the PC end.

Q: What’s the standard cable length?
A: Its standard length is 3 m. But it can be customized, MAX can be 1 KM.

Q: What's the lifetime of this Mini Ultrasonic Wind Speed Wind Direction Sensor?
A: At least 5 years long.

Q: May I know your warranty?
A: Yes, usually it’s 1 year.

Q:What’s the delivery time?
A: Usually, the goods will be delivered in 3-5 working days after receiving your payment. But it depends on your quantity.

Q: What industry can be applied to in addition to construction sites?
A:Urban roads,bridges,smart street light, smart city,industrial park and mines, etc.
