Outdoor Rs485 Modbus Temperature Humidity Wind Speed Wind Direction Atmospheric Pressure Illuminance Rainfall Weather Station
Features
1. It is equipped with standard equipment to monitor the measurement of seven parameters including atmospheric temperature, relative humidity, wind speed, wind direction, atmospheric pressure, illuminance and rainfall. (Optional dew point temperature, total radiation, sunshine hours, transpiration parameter measurement)
2. Exquisite appearance, highly integrated structure, designed with reference to meteorological standards;
3. Reliable performance, suitable for outdoor fields with severe weather conditions.
4. Installation-free, environmental protection and energy saving, can completely replace the traditional patchwork agricultural weather station type.
5.RS485 modbus protocol and can use the LORA/ LORAWAN/ GPRS/ 4G/WIFI wireless data transmission, and the LORA LORAWAN frequency can be custom made.
6.The matched cloud server and software can be supply if using our wireless module.
It has basic three functions.
1. See real time data in the PC end
2. Download the history data in excel type.
3. Set alarm for each parameters which can send the alarm information to your email when the measured data are out of range.
Product Application
Application field
● Weather monitoring
● Urban environmental monitoring
● Wind power
● Navigation ship
● Airport
● Bridge tunnel
●Agricultural Meteorology
Product parameters
|
Measurement parameters |
|||
| Parameters Name | 7 in 1: Ultrasonic wind speed ,wind direction,air temperature, air relative humidity, atmospheric pressure,Illumination,tipping bucket rainfall | ||
| Parameters | Measure range | Resolution | Accurancy |
| Wind speed | 0-40m/s | 0.1m/s | ±(0.5+0.05v)m/s |
| Wind direction | 0-359.9° | 0.1° | ±5° |
| Air temperature | -40-60℃ | 0.1℃ | ±0.3℃（25℃） |
| Air relative humidity | 0-100%RH | 0.1% | ±3%RH |
| Atmospheric pressure | 300-1100hpa | 0.1hpa | ±0.3hPa |
| Illumination | 0-200Klux | 10lux | ±3%或1%F.S |
| Rainfall | ≤4mm/min | 0.2mm | ±0.4mm(R≤10mm)±4%（R＞10mm） |
| Total radiation | 0-2000W/㎡ | 1W/㎡ | ＜±5%(600w/㎡~1000w/㎡ |
| Sunshine hours | 0-24h | 0.1h | 5% |
| Dew point temperature | 0-40℃ | 0.1℃ | ≤0.5℃（0℃-30℃ 40%RH~100%RH） ＞1℃（＜0℃，＜40%RH） |
| ET value | 0-80mm/d | 0.1mm/d | ±25% |
| * Other customizable parameters | Radiation, PM2.5,PM10,Ultraviolet, CO,SO2, NO2, CO2, O3 | ||
|
Monitoring principle |
Air temperature and humidity: Swiss Sensirion digital temperature and humidity sensor | ||
| Illumination: German ROHM digital photosensitive chip | |||
| Rainfall: Tipping bucket rain gauge | |||
| Technical parameter | |||
| Stability | Less than 1% during the life of the sensor | ||
| Response time | Less than 10 seconds | ||
| Warm-up time | 30S (SO2 \ NO2 \ CO \ O3 12 hours) | ||
| Supply voltage | 12-24VDC | ||
| Working current | DC12V≤60ma (HCD6815) -DC12V≤180ma | ||
| Power consumption | DC12V≤0.72W (HCD6815); DC12V≤2.16W | ||
| Life time | In addition to SO2 \ NO2 \ CO \ O3 \ PM2.5 \ PM10 (normal environment for 1 year, high pollution environment is not guaranteed), life is not less than 3 years |
||
| Output | RS485, MODBUS communication protocol | ||
| Housing material | ASA engineering plastics | ||
| Working environment | Temperature -30 ～ 70 ℃, working humidity: 0-100% | ||
| Storage conditions | -40 ~ 60 ℃ | ||
| Standard cable length | 3 meters | ||
| The farthest lead length | RS485 1000 meters | ||
| Protection level | IP65 | ||
| Electronic compass | Optional | ||
| GPS | Optional | ||
| Wireless transmission | |||
| Wireless transmission | LORA / LORAWAN(eu868mhz,915mhz,434mhz), GPRS, 4G,WIFI | ||
| Cloud Server and Software introduce | |||
| Cloud server | Our cloud server is bind up with the wireless module | ||
| Software function | 1. See real time data in the PC end | ||
| 2. Download the history data in excel type | |||
| 3. Set alarm for each parameters which can send the alarm information to your email when the measured data are out range. | |||
| Mounting Accessories | |||
| Stand pole | 1.5 meters, 1.8 meters ,3 meters higth, the other higth can be customize | ||
| Equiment case | Stainless steel waterproof | ||
| Ground cage | Can supply the matched ground cage to burried in the ground | ||
| Lightning rod | Optional(Used in thunderstorm places) | ||
| LED display screen | Optional | ||
| 7 inch touch screen | Optional | ||
| Surveillance cameras | Optional | ||
| Solar power system | |||
| Solar panels | Power can be customized | ||
| Solar Controller | Can provide matched controller | ||
| Mounting brackets | Can provide the matched bracket | ||
Product installation
FAQ
Q: What's the main characteristics of this compact weather station?
A: It can measure the air temperature humidity pressure wind speed wind direction rainfall 6 parameters at the same time, and the other parameters also can be custom made.It is easy for installation and has robust & integrated structure, 7/24 continuous monitoring.
Q:Can we choose other desired sensors?
A: Yes, we can supply the ODM and OEM service, the other required sensors can be integrated in our present weather station.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:Do you supply tripod and solar panels?
A: Yes, we can supply the stand pole and the tripod and the other install accessories, also the solar panels, it is optional.
Q: What’s the common power supply and signal output?
A: Common power supply and signal output is DC: 12-24 V , RS 485. The other demand can be custom made.
Q: Which output of the sensor and how about the wireless module?
A: You can use your own data logger or wireless transmission module if you have , we supply the RS485-Mudbus communication protocol.We can also supply the matched LORA/LORANWAN/GPRS/4G wireless transmission module.
Q: How can I collect the data and can you supply the matched server and software?
A: We can supply three ways to show the data:
(1) Integrate the data logger to store the data in the SD card in excel type
(2) Integrate the LCD or LED screen to show the real time data indoor or outdoor
(3) We can also supply the matched cloud server and software to see the real time data in the PC end.
Q: What’s the standard cable length?
A: Its standard length is 3 m. But it can be customized, MAX can be 1 Km.
Q: What's the lifetime of this weather station?
A: We use the ASA engineer material which is anti-ultraviolet radiation which can be used for 10 years outside.
Q: May I know your warranty?
A: Yes, usually it’s 1 year.
Q:What’s the delivery time?
A: Usually, the goods will be delivered in 3-5 working days after receiving your payment. But it depends on your quantity.
Q: What industry can be applied to in addition to construction sites?
A:Urban roads,bridges,smart street light, smart city,industrial park and mines, etc.
