Online Weather Monitoring Mini Ultrasonic Wind Speed and Direction Weather Station
Video
Features
●This product is small in size, light in weight, high-quality anti-ultraviolet material, long service life, high-sensitivity probe, stable signal and high precision.
●Which are stable and reliable, and have the characteristics of wide measurement range, good linearity, good waterproof performance, convenient use, easy installation, and long transmission distance.
●RS485 communication interface Can be connected to GPRS, 4G, LORA, LORAWAN WIFl modules to achieve wireless transmission
●Send matched cloud server and software
Product Functions
The matched cloud server and software can be supply if using our wireless module. It has basic three functions:
1. See real time data in the PC end.
2. Download the history data in excel type.
3. Set alarm for each parameters which can send the alarm information to your email when the measured data are out range.
Product Application
This product is widely used in various occasions that need to measure environmental temperature and humidity, noise, air quality, CO2, atmospheric pressure, etc. It is safe and reliable, beautiful in appearance, easy to install, and durable.
Product Parameters
|
Measurement parameters |
|||
| Parameters name | Ultrasonic weather station | ||
| Parameters | Measure range | Resolution | Accuracy |
| Wind speed | 0-40m/s | 0.01m/s | ±0.5+2% FS |
| Wind direction | 0-359° | 1° | ±3° |
| Humidity | 0%RH~99%RH | ≤1% | ±3%RH(60%RH,25℃) |
| Temperature | -40℃~+120℃ | ≤0.1℃ | ±0.5℃（25℃） |
| Light intensity | 0~200000Lux | ≤5% | ±7%(25℃) |
| Atmospheric pressure | 0-120Kpa | -0.1Kpa | ±0.15Kpa@25℃ 75Kpa |
| Noise | 30dB~120dB | ≤3db | ±3db |
| PM10 PM2.5 | 0-1000ug/m3 | ≤1% | ±10%（25℃） |
| Rain gauge | 24mm/min | 0.1mm | ±5% |
| * Other customizable parameters | Other parameters can be customized according to your requirements | ||
|
Technical parameter |
|||
| Stability | Less than 1% during the life of the sensor | ||
| Response time | Less than 10 seconds | ||
| Working current | DC12V≤60ma | ||
| Output | RS485, MODBUS communication protocol | ||
| Housing material | ABS engineering plastics anti UV | ||
| Working environment | Temperature -30 ～ 70 ℃, working humidity: 0-100% | ||
| Storage conditions | -40 ~ 60 ℃ | ||
| Standard cable length | 2 meters | ||
| The farthest lead length | RS485 1000 meters | ||
| Protection level | IP65 | ||
|
Wireless transmission |
|||
| Wireless transmission | LORA / LORAWAN, GPRS, 4G,WIFI | ||
|
Mounting Accessories |
|||
| Stand pole | 1.5 meters, 2 meters ,3 meters high, the other high can be customize | ||
| Equipment case | Stainless steel waterproof | ||
| Ground cage | Can supply the matched ground cage to burred in the ground | ||
| Lightning rod | Optional(Used in thunderstorm places) | ||
| LED display screen | Optional | ||
| 7 inch touch screen | Optional | ||
| Surveillance cameras | Optional | ||
|
Solar power system |
|||
| Solar panels | Power can be customized | ||
| Solar Controller | Can provide matched controller | ||
| Mounting brackets | Can provide the matched bracket | ||
|
Matched cloud server and software |
|||
| Cloud server | If buy our wireless modules | ||
| Free software | See real time data and download the history data in excel | ||
FAQ
Q: What's the main characteristics of this compact weather station?
A: It is multi parameters weather station including the air temperature humidity pressure PM2.5 PM10 Noise , IR rainfall parameters ultrasonic wind speed and direction . And above parameter can be custom made according to your requirements. It is easy for installation and has robust & integrated structure, , 7/24 continuous monitoring.
Q:Can we choose other desired sensors?
A: Yes, we can supply the ODM and OEM service, the other required sensors can be intergrated in our present weather station.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:Do you supply tripod and solar panels?
A: Yes, we can supply the stand pole and the tripod and the other install accessory, also the solar panels, it is optional.
Q: What’s the common power supply and signal output?
A: Common power supply and signal output is DC: 12-24V, RS485 . The other demand can be custom made.
Q: How can I collect data?
A: You can use your own data logger or wireless transmission module if you have , we supply the RS485-Mudbus communication protocol.We can also supply the matched LORA/LORANWAN/GPRS/4G wireless transmission module.
Q: Can we have the screen and the data logger?
A: Yes, we can match the screen type and data logger which you can see the data in the screen or download the data from the U disk to your PC end in excel or test file.
Q: Can you supply the software to see the real time data and download the history data?
A: We can supply the wireless transmission module including the 4G,WIFI,GPRS , if you use our wireless modules, we can supply the matched server and free software which you can see the real time data and download the history data in the software directly.
Q: What’s the standard cable length?
A: Its standard length is 1 m. But it can be customized, MAX can be 1KM.
Q: What's the lifetime of this Mini Ultrasonic Wind Speed Wind Direction Sensor?
A: At least 5 years long.
Q: May I know your warranty?
A: Yes, usually it’s 1 year.
Q:What’s the delivery time?
A: Usually, the goods will be delivery in 3-5 working days after receiving your payment. But it depends on your quantity.
Q: What industry can be applied to in addition to construction sites?
A:Urban roads,bridges,smart street light, smart city,industrial park and mines, etc.
