Modbus GPS BDS Glonass Navigation Multi-system Joint Positioning Sensor
Features
1.Industrial dual-mode positioning chip, support GPS positioning and Beidou positioning
2.Precise location, using WGS84 world geodetic coordinate system, accurate location of latitude and longitude information
3.Overcurrent protection, surge prevention. RS232/485 with TVS high performance protection device
4.Self-diagnosis function, providing status information such as antenna open circuit and short circuit
5.Strong compatibility, support BDS/GPS/GLONASS satellite navigation system multi-system joint positioning
6.Easy installation, simple operation, only need to connect the antenna power can work
Application
Product parameters
| Product Name | GPS BDS positioning sensor |
| Power supply | DC 7~30V |
| Power consumption | 0.348w |
| Use environment | Working temperature -20℃~+60℃, 0%RH~95%RH non-condensing |
| Communication interface | RS232/485 interface is optional |
| Communication baud rate | 1200~115200 can be set |
| Antenna interface | Connect to the GPS+Beidou dual-frequency antenna provided by our company |
| Positioning accuracy | 2.5 meters (CEP50) |
| Altitude Typical accuracy | +-10 meters |
| Ground speed | <0.36km/h (1σ) |
| Monitoring parameters | Positioning status, longitude, latitude, speed over ground, heading over ground, altitude, antenna status, time year, month, day, hour, minute, second |
FAQ
Q: What's the main characteristics of this positioning module?
A: It is GPS and BDS dual-mode positioning, with more accurate positioning and more measurement parameters.
Q:Can we choose other desired sensors?
A: Yes, we can supply the ODM and OEM service.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q: What’s the common power supply and signal output?
A: Common power supply and signal output is DC: 10-30 V , RS 485,RS232.
Q: Which output of the sensor and how about the wireless module?
A: You can use your own data logger or wireless transmission module if you have , we supply the RS485-Mudbus communication protocol. We can also supply the matched LORA/LORANWAN/GPRS/4G wireless transmission module.
Q: How can I collect the data and can you supply the matched server and software?
A: We can supply three ways to show the data:
(1) Integrate the data logger to store the data in the SD card in excel type
(2) Integrate the LCD or LED screen to show the real time data
(3) We can also supply the matched cloud server and software to see the real time data in the PC end.
Q: May I know your warranty?
A: Yes, usually it’s 1 year.
Q:What’s the delivery time?
A: Usually, the goods will be delivered in 3-5 working days after receiving your payment. But it depends on your quantity.
